Biomedical Materials Tester

The Biomaterials Mechanical Testing Machine is a precision testing device specifically designed to evaluate the mechanical properties of biomedical materials (such as bone, cartilage, li...

Dynamic Fatigue Test System fo

None

　　The Biomaterials Mechanical Testing Machine is a precision testing device specifically designed to evaluate the mechanical properties of biomedical materials (such as bone, cartilage, ligament, tendon, skin, blood vessels, hydrogels, artificial implants, etc.). This equipment can assess the mechanical behavior of biomaterials under simulated physiological environments, providing critical data support for biomaterials research, development, quality control, and clinical applications.

Test Type	Test Purpose
Tensile Test	Determines tensile strength, elastic modulus, elongation at break
Compression Test	Determines compressive strength, compressive modulus, yield point
Flexural/Bend Test	Determines flexural strength, flexural modulus
Shear Test	Determines shear strength, shear modulus
Fatigue Test	Evaluates durability under cyclic loading
Creep Test	Measures deformation over time under constant load
Stress Relaxation Test	Measures stress decay over time under constant deformation
Peel/Adhesion Test	Evaluates adhesion performance at tissue-material interfaces
Torsion Test	Determines torsional strength, torsional stiffness

Standard No.	Standard Name	Key Content
ASTM F2150	Standard Guide for Characterization and Testing of Biomaterial Scaffolds Used in Tissue-Engineered Medical Products	Guide for characterization and testing of tissue engineering scaffolds
ISO 527	Plastics — Determination of tensile properties	Tensile properties determination for plastics
ISO 178	Plastics — Determination of flexural properties	Flexural properties determination for plastics
ASTM D638	Standard Test Method for Tensile Properties of Plastics	Tensile properties test method for plastics
ASTM D695	Standard Test Method for Compressive Properties of Rigid Plastics	Compressive properties test method for rigid plastics
ISO 14801	Dentistry — Implants — Dynamic loading test	Dynamic fatigue test for dental implants
YY/T 0959	Spinal implants — Test methods for mechanical property of intervertebral body fusion devices	Mechanical performance test for intervertebral fusion cages

Parameter	Typical Range	Description
Maximum Load	100N ~ 100kN	Low range for soft tissue, high range for hard tissue
Load Accuracy	Class 0.5 / Class 1	Indicated value accuracy grade
Speed Range	0.001 ~ 1000 mm/min	Stepless speed adjustment
Displacement Resolution	0.01 mm / 0.001 mm	High-precision optical encoder measurement
Test Stroke	100 ~ 1000 mm	Select based on material dimensions
Temperature Control	-40°C ~ 250°C / 37°C ± 1°C	Environmental chamber or temperature-controlled bath
Waveform Types	Sine, triangle, square, sawtooth, custom waveforms	For dynamic testing
Power Supply	220V / 380V, 50Hz	Depending on model configuration
Equipment Weight	Approx. 50 ~ 1000 kg	Depending on model configuration
